Electrical Door Lock Electrical Solenoid Valve 12V LY-03 LY-01 Electromagnetic Lock 12V 700mA DC

Product Description

📌 All items in our store are ready stock, and will ship within 1 day after order. Our shop open 365 day non-stop 👍 【Description】 The work principle of this solenoid are pretty simple. An input of 12V can trigger the solenoid magnetic to unlock, and when the power is cutoff the solenoid is lock again. Keep in mind that the unlock time should be control in maximum 15 second, recommended < 10s maximum unlock. Mostly pair with relay and microcontroller to control over it. If unlock for too long, it may consume much energy and the module will be warm up, end up it may destroy the magnetic valve controller inside. ⚠️【Caution 】 For normal version, it only can power on for short period of time, recommended <10, else it will heat up and damage the coil. For the enhance version that allow longer period of power on, it can on up to 8 hour, but the casing will be hot till 80 degree !! Please take notes on the casing ! And the basic principle of the solenoid valve was not design for longer period of locking ~ 【Specification】 Power consumption when unlock : 750mA @ 12V 【Application】 Door Lock, IOT locker 📝【Size】 Refer back to the photo 【Package Include】📦 - 1 solenoid valve 12v #DoorLock #Solenoid #Electrical #Electromagectic Door Lock
