RFID RC522 RC-522 RC 522 MFRC522 13.56MHz IC ID Card Reader Detector Module

Product Description

📌 Overview This module can be directly loaded into the various reader molds, very convenient. It is very easy to use as there are tones of library and examples, especially using Arduino. It is based on the MF522-AN module and ready with the RFID antenna built in. MFRC522 are similar to MFRC500 or MFRC530 , but also have the characteristics and differences. Communication between it and the host SPI mode helps to reduce the connection narrow PCB board volume, reduce costs. The MFRC522 use of advanced modulation and demodulation concept completely integrated in all types of 13.56MHz passive contactless communication methods and protocols MFRC522 is applied to the highly integrated read and write 13.56MHz contactless communication card chip. Low-voltage, low-cost, small size of the non-contact card chip to read and write Smart meters and portable handheld devices developed better choice. 📊 Specifications Operating Current :13-26mA/DC 3.3V Idle Current :10-13mA/DC 3.3V Sleep Current: <80uA Peak Current: <30mA Operating Frequency: 13.56MHz Supported card types: mifare1 S50, mifare1 S70, mifare UltraLight, mifare Pro, mifare Desfire and mifare Classic Environmental Operating Temperature: -20-80 degrees Celsius Environmental Storage Temperature: -40-85 degrees Celsius Relative humidity: relative humidity 5% -95% Data transfer rate: maximum 10Mbit/s Size: RFID-RC522 Module:3.9 x 6 cm The Standard S50 Blank Card :8.5 x 5.4 cm Diameter of S50 special-shaped card: 3.1(max) 📦 Packing List: 1 x RC522 board 1 x 13.56MHz Key tag 1 x 13.56MHz Card
