STM32F030F4P6 Development Board Embedded Project

Product Description

The STM32F030x4/x6/x8/xC microcontrollers incorporate the high-performance Arm® Cortex®-M0 32-bit RISC core operating at a 48 MHz frequency, high-speed embedded memories (up to 256 Kbytes of Flash memory and up to 32 Kbytes of SRAM), and an extensive range of enhanced peripherals and I/Os. All devices offer standard communication interfaces (up to two I2Cs, up to two SPIs and up to six USARTs), one 12-bit ADC, seven general-purpose 16-bit timers and an advanced-control PWM timer. Specification - Core: Arm® 32-bit Cortex®-M0 CPU, frequency up to 48 MHz - Memories 16 Kbytes of Flash memory, 4 Kbytes of SRAM with HW parity - CRC calculation unit - Reset and power management - Clock management - One 12-bit, 1.0 µs ADC (up to 16 channels) Communication interfaces - Up to two I2C interfaces - Fast Mode Plus (1 Mbit/s) support onone or two I/Fs, with 20 mA current sink -SMBus/PMBus support (on single I/F) - Up to six USARTs supporting master synchronous SPI and modem control; one with auto baud rate detection - Up to two SPIs (18 Mbit/s) with 4 to 16 programmable bit frames Reference Link https://www.st.com/en/microcontrollers-microprocessors/stm32f030f4.html Datasheet - https://www.st.com/resource/en/datasheet/stm32f030f4.pdf Resource link - Example project please contact our customer service
