TB6600 Stepper Motor Driver MicroStep Stepper Motor Driver NEMA17 Stepper Driver Motor 42/57 4A

Product Description

📌 All items in our store are ready stock, and will ship within 1 day after order. Our shop open 365 day non-stop 👍 【Description】 The TB6600 Stepper Motor Driver is an easy-to-use professional stepper motor driver, which could control a two-phase stepping motor. 【Features】 1- 9V-42V DC power supply; 2- H-bridge bipolar constant-phase flow-driven; 3- The maximum output current of 4.0A eight optional; 4- Up to 32 segments of six kinds of sub-modes available; 5- The input signal is high-speed optical isolation; 6- Standard common anode single pulse interface; 7- Semi-enclosed chassis can accommodate more demanding environment; 8- Provide energy semiautomatic current lock function; 9- Built-in thermal protection and overcurrent protection. 【Specification】 - Voltage Input: 9 to 42VDC - Input Current: 0~5A - Output Current: 0.5-4.0A - Max Power: 160W - Micro Step: 1, 2/A, 2/B, 4, 8, 16, 32 - Weight: 0.2 kg 【Size and Dimension】 - Dimension: 9.6 x 5.6 x 3.3 cm 【Package Include】📦 1 x TB6600 #TB6600
